Architettura Sonora Icarus Sub

Since longer wavelengths, low-end frequencies are able to pass through most obstacles, that is why the ICARUS_SUB has been designed, so to be easily placed everywhere, indoor and outdoor, hidden or exposed, in order to integrate seamlessly with any design or material due to its extremely elegant and refined design supporting any kind of low-frequency need without compromising sound quality.

Description

Icarus Sub - High quality designer products | Architonic

Icarus Sub

Since longer wavelengths, low-end frequencies are able to pass through most obstacles, that is why the ICARUS_SUB has been designed, so to be easily placed everywhere, indoor and outdoor, hidden or exposed, in order to integrate seamlessly with any design or material due to its extremely elegant and refined design supporting any kind of low-frequency need without compromising sound quality.

This powerful subwoofer has been specifically designed to complete and support the Icarus family satellites, but can be very useful with the whole range of AS models, particularly suitable for pairing with Cylinders, considering its design.

Architettura Sonora

Version Subwoofer without crossoverSubwoofer with crossover on board
Speaker Type8″ woofer 8″ woofer
Nominal Impedance
CrossoverRecommended DSP setting:
HP=35Hz; 12dB/oct
LP=120Hz; 12dB/oct
LP=150Hz; 12dB/oct
Frequency Range 40-150Hz (-6dB)
(recommended DSP setting)
40-150Hz (-6dB)
Sensitivity (1W – 1m)87dB87dB
Speaker Peak Power400W400W
Speaker RMS Power 200W200W
Lighting Mood N/AN/A
High-z Board Optional
(voltage: 70-100V
Power: 30-60W)
Optional
(voltage: 70-100V
Power: 30-60W)
Dimensions34 h x 27 cm di diam.
Weight22 Kg Concrete; 24 Kg Marble

Materials
