Control4 T4 Series 10” In-Wall Touchscreen POE (Black/White)

Control4 T4 Series 10” In-Wall Touchscreen POE (Black/White)

Give your customers the ultimate smart home experience with the Control4 T4 Touchscreen. As a direct replacement for the T3 Touchscreen, T4 delivers a high-resolution screen, dual microphones, and more powerful speakers than the T3. With its elevated features, T4 is the perfect companion for the new Control4 Chime Video Doorbell, OS 3, and Intercom Anywhere.

In-wall touchscreens give your customers a point of complete control that is always on and always available in a convenient predictable place.

T4’s installer-friendly design helps you install more systems faster. It requires no special tools to install or remove from the wall. High-strength magnets secure it in place. Plus, T4 uses the same backbox as T3 for stress-free retrofit jobs, making T4 a simple, yet impactful upgrade for every smart home.

  • This SKU includes a PoE mid-box to provide power to the touchscreen
  • This SKU must be connected via CAT cable to a PoE powered port
  • Available in black and white finishes, and in 8″ and 10″ sizes
  • Screen Resolution: 1920 x 1200
  • Dual microphones and larger speakers
  • An elevated experience for Chime, OS 3, and Intercom Anywhere
  • Network connection via PoE or Wi-Fi (2.4 GHz + 5 GHz)
  • Tool-less installation and removal
  • High-strength magnets and tamper-resistant screws
  • Compatible with T3 backbox

IMPORTANT NOTE: A backbox is required to install the Control4 T4 Touchscreen, and is sold seperately.

Categories: , ,

Description

Control4Control4 Touchscreens offer a complete view and dedicated control of your entire home. Unlike traditional touchscreens, you won’t need to find and launch an app; control of your home is instantaneous. Conveniently manage lighting, security, music, televisions, temperature, shades, and more. Their bright, high-resolution screens, fast processors, advanced microphone array, and high-grade speakers are excellent for security cameras and video doorbells, as well as intercom from room to room, or from home to mobile device. Choose from 8” or 10” in glossy black or white, and tabletop or in-wall mounting options.

  • Delivers always-on, dedicated control over all the technology in your home.
  • Browse playlists with a simple swipe, display bold cover art images, and easily personalize your lighting experience.
  • HD video intercom and crystal-clear audio allows convenient communication from room to room or with visitors at the door.
  • Low-profile design and crisp, high-resolution picture.
  • You’ll always know where to find it; mounted on the wall or placed on the charging stand.
Features
ScreenResolution: 1920 x 1200
Capacitive touch
Camera: 720p
Wireless network802.11b/g/n 2.4 GHz
802.11a/n/ac 5 GHz
Security: WEP, WPA/WPA2 PSK, 802.1x EAP, PEAP
Power SupplyTabletop models: International power supply adapters included Tabletop charging station connections: 5V DC power
In-wall: PoE (IEEE 802.3af) 13W peak
Mechanical
Dimensions (W x H x D)Tabletop:
* 8″ Touchscreen: 200 x 144 x 23 mm (7.9” x 5.7” x 0.9″)
* 8″ Charging station: 106 x 79 x 56 mm (4.17″ x 3.11″ x 2.21″)
* 10″ Touchscreen: 245 x 172 x 23 mm (9.65″ x 6.77″ x 0.9″)
* 10″ Charging station: 115 x 102 x 66 mm (4.53″ x 4.02″ x 2.60″)
In-wall:
* 8″ model: 202 x 142 x 15 mm (8.0″ 5.6″ x 0.59″)
* 10″ model: 246 x 172 x 15 mm (9.69″ x 6.77″ x 0.59″)

(See Planning template on back page for outline details)

* Power box: 127 x 119 x 45 mm (5.0″ x 4.67″ x 1.77″)
WeightTabletop:
* 8″ Touchscreen: 0.47kg (1.05 lb)
* 8″ Charging base: 0.64kg (1.4 lb)
* 10″ Touchscreen: 0.60kg (1.35 lb)
* 10″ Charging base: 0.46kg (1.05 lb)
In-wall (with mid-box):
* 8″ model: 0.41kg (0.9 lb)
*10″ model: 0.68kg (1.5 lb)
Environmental
Operating temperature0 to 40˚C (32 to 104˚F)
Storage temperature-20 to 70˚C (-4 to 158˚F)
