Large, Sharp, Impactful Viewing Experience.

The WUXGA EB-FH52 projector features 1.2x optical zoom for flexible installation in virtually any room. Offering remarkable color accuracy, Epson projectors deliver high Color Brightness. The EB-FH52 features 4,000 lumens of color/white brightness2, plus WUXGA resolution. Its long-lasting lamp, which delivers up to 12,000 hours in ECO Mode3, lowers maintenance costs. Optional wireless connectivity offers simultaneous display of multiple screens.

  • Projection System: 3LCD, 3-chip technology
  • Native Resolution: 1920 x 1080(Full HD)
  • Color Brightness: 4,000 lumens
  • White Brightness: 4,000 lumens
Categories: , ,

Description

Product Brochure

Full HD 1080p Resolution

Displaying clear and crisp visuals thanks to its Full HD 1080p format, the Epson EB-FH52’s high resolution is able to support vivid display on large screen sizes. Improved connectivity ensures smooth communication between your smart devices and the projector, making presentations hassle-free.

Screen Mirroring with Miracast®

Miracast support makes it easy to connect smart devices or laptops to a projector. This feature can be used without additional options or the installation of an application for wireless connection. Quick wireless connection makes the presentation smart and eliminates annoying cabling.

Easy Maintenance and Longer Lamp Life

A long lamp life reduces maintenance and costs. The lamp will last up to 12,000 hours in ECO mode. Cut down on the frequency of lamp replacements, saving you time and money, and lowering the total cost of ownership.

Projection TechnologyRGB liquid crystal shutter projection system (3LCD)
LCDSize0.61” (C2fine)
Native Resolution1080p
LightsourceType230W UHE
Life (Normal / Eco)5,500 / 12,000 hours
Aspect Ratio16:9
Projection LensTypeOptical Zoom (Manual) / Focus (Manual)
F-Number1.51 – 1.99
Focal Length18.20 – 29.20 mm
Zoom Ratio1 – 1.6
Throw Ratio1.32 – 2.14 (Wide to Tele)
StandardTele: 30” to 300” [1.42 to 14.41 m]
Wide: 30” to 300” [0.87 to 8.88 m]
White Light Output (Normal / Extended)4,000 lm
Colour Light Output4,000 lm
Contrast Ratio16,000:1
Geometric CorrectionVertical / Horizontal Keystone±30° / ±30° (Auto Vertical Keystone only)
Quick CornerYes
Split ScreenYes
Internal SpeakersMonoaural: 2W x 1
Analog InputD-Sub 15Pin1
Composite1 (RCA)
Digital InputDVI-DNA
HDMI2
HDBaseTNA
Output TerminalD-Sub 15PinNA
HDMINA
Audio Input2RCA (White & Red) 1
Audio OutputStereo Mini JackNA
OthersUSB Type A1 (For Wireless LAN, Firmware Update, Copy OSD Settings)
USB Type B1 (For Firmware Update , Copy OSD Settings)
Control I/ORS-232CNA
Remote Control InputNA
NetworkWired LANNA
WirelessBuilt-In
Wireless Specification (Screen Mirroring)Supported Speed For Each ModeIEEE 802.11g (2.4GHz): 54Mbps*2 / IEEE 802.11n (2.4GHz): 130 Mbps*2 / IEEE 802.11a (5GHz): 54 Mbps*2 /
IEEE 802.11n (5GHz): 270 Mbps*2 / IEEE 802.11ac (5 GHz): 780 Mbps*2
Wireless Specification (Built-in Wireless LAN)Supported Speed For Each ModeIEEE 802.11b (2.4GHz): 11Mbps*2 / IEEE 802.11g (2.4GHz): 54 Mbps*2 / IEEE 802.11n (2.4GHz): 72.2 Mbps*2 /
IEEE 802.11a (5GHz): 54 Mbps*2 / IEEE 802.11n (5 GHz): 150 Mbps*2
Wireless LAN SecurityQuick Mode: OPEN, WPA2-PSK (AES)
Advanced Mode: OPEN, WPA2/WPA3-PSK, WPA2/WPA3-EAP
Supported EAP Type: PEAP, PEAP-TLS, EAP-TLS, EAP-Fast
Operating TemperatureLow Altitude: 5 – 40 °C <41 – 104 °F> High Altitude: 5 – 35 °C <41 – 95 °F>
(20% – 80% Humidity, No Condensation)
Operating Altitude0 – 3,048 m <0 – 10,000 ft>
Direct Power On / OffYes
Start-Up PeriodUp to 6 seconds, Warm-up Period: 30 seconds
Cool Down PeriodInstant Off
TypeHigh Efficiency Filter
Maintenance Cycle (Normal / Eco)10,000 / 20,000 hours
Power Supply Voltage100 – 240 V AC ±10%, 50/60 Hz
Power Consumption (220 – 240V)Lamp (Normal / Eco)327W / 225W
Standby (Energy Saving)2.0W / 0.3W
Dimension Excluding Feet (D X W X H)282 x 309 x 90 mm
Weight (Including Standard Lens)Approx. 3.1 kg
Fan Noise (Normal / Quiet)37dB / 28dB
