Projection Technology: | RGB liquid crystal shutter projection system (3LCD) |
Brightness: | White Light Output (Normal/Eco):4,200 lmColour Light Output:4,200 lm |
Connections | USB Interface:USB Type A: 1 (for Wireless LAN, Firmware Update, Copy OSD Settings) |
USB Type B: 1 (for Firmware Update, Copy OSD Settings)Network:Wireless: 1 (ELPAP11) |
Wired LAN: 1Analog Input:Composite: 1 RCA |
D-Sub 15pin: 2Digital Input:HDMI: 2Output Terminal:D-Sub 15Pin: 1Audio Input:Stereo Mini: 2 |
2RCA (White & Red): 1Audio Output:Stereo Mini Jack: 1Mic I/O:Stereo Mini: 1Control I/O:RS-232C: 1 |
Contrast Ratio: | 16,000:1 |
Screen Size (Projected Distance): | Tele: 29” to 280” [1.40 to 13.71 m] |
Wide: 29” to 280” [0.85 to 8.45 m] |
Geometric Correction: | Vertical/Horizontal Keystone:±30° / ±30° (Auto Vertical Keystone only)
Quick Corner:Yes |
Operating Temperature: | Low Altitude: 5 – 40 °C High Altitude: 5 – 35 °C |
(20% – 80% Humidity, No Condensation) |
Operating Altitude: | 0 – 3,048 m |
Start-Up Period: | Up to 6 seconds, Warm-up Period: 30 seconds |
Cool Down Period: | Instant Off |
Direct Power On/Off: | Yes |
Dimension Excluding Feet (W x H x D): | 309 x 90 x 282 mm |
Weight: | 3.1 kg |
Air Filter: | Type:High Efficiency FilterMaintenance Cycle:10,000 / 20,000 hours*3 |
Fan Noise(Normal / Eco): | 37dB / 28dB |
Power: | 100 – 240 V AC ±10%, 50/60 Hz |
Projectors Facets: | Resolution, Projectors Facets:WXGAContrast Ratio, Projectors Facets:16,000:1Brightness Range Lumens, Projectors Facets:4001Features, Projectors Facets:Wifi |
Quick CornerLaser / Lamp, Projectors Facets:Lamp |
Optional Wireless & Built In Lan Specifications: | Supported Speed for each Mode:IEEE 802.11b (2.4GHz): 11 Mbps*2 |
IEEE 802.11g (2.4GHz): 54 Mbps*2 |
IEEE 802.11n (2.4GHz): 72.2 Mbps*2 |
IEEE 802.11a (5GHz): 54Mbps*2 |
IEEE 802.11n (5GHz): 150 Mbps*2Wireless LAN Security:Infrastructure: OPEN, WPA2/WPA3-PSK |
Access Point: OPEN, WPA2-PSK (AES) |
