Marantz PM7000N

Marantz PM7000N

Discover the PM7000N, the first Marantz fully discrete, current feedback integrated Hi-Fi amplifier with HEOS Built-in technology. The ideal choice for audiophiles, the PM700N includes high-grade audio components, current feedback HDAMs, a toroidal transformer and a high-speed instantaneous current power supply. Stream music wirelessly, or enjoy high-resolution digital audio files up to 24 bits and 192 kHz sampling.

  • Power to suit your audio preference
  • Wide range of connectivity
  • Flexibility for all configurations
  • Marantz proprietary HDAM-SA3 circuit
  • Newly designed electric volume circuit
  • Play vinyl with exceptional clarity
  • Premium Marantz SPKT-1+ speaker terminals
  • Stream music from your favorite sources
  • Speak your commands
  • High-performance, high-resolution audio playback
  • Built-in Bluetooth and Wi-Fi with 2.4GHz/5GHz dual band support
  • Works with your TV remote
Categories: , ,

Description

Modern Integrated Amplifier

The PM7000N is the first fully discrete, current feedback integrated Hi-Fi amplifier with HEOS Built-in technology from Marantz. It is the ideal choice for audiophiles that require Marantz Musical sound with flexible operation and access to digital streaming music. The amplifier delivers a powerful 2x 60W into 8 ohm or 2 x 80W into 4 ohm (20Hz – 20kHz).

Fully Discrete Current Feedback Power Amplifier

Current Feedback amplification, a renowned Marantz-proprietary circuit technology, is thoughtfully designed to match the requirements of Super Audio hi-res music for wide-bandwidth, high-speed reproduction. The impedance at the Current Feedback point is limited, generating a very low phase shift. Marantz Current Feedback amplifiers reduce the need for phase compensation by minimizing Negative Feedback (NFB).

Marantz HDAM-SA3 Technology

Marantz developed its own discrete circuit boards called Hyper-Dynamic Amplifier Modules, or HDAMs, to replace the chip-based amps used elsewhere. Using discrete surface mount components with short mirror-image left and right signal paths, HDAMs outperform the regular integrated Op-amps dramatically in Slew Rate and noise level. The result is much more dynamic, accurate and detailed sound. Over the years, Marantz developed different HDAMs to fit the particular requirements of each player and amplifier. The PM7000N uses the high-grade SA3 version.

The Most Musical Sound

Engineered and extensively tuned by a team drawing on 70 years of Hi-Fi expertise, the PM7000N provides exceptional performance for your audio collection. Whether digital or analog, enjoy the most musical sound from any source.
Features
Channels2
Cureent Feedback TopologyYes
HDAM versionHDAM-SA3, SA2
Power TransformerToroidal
High Grade Audio ComponentsYes
Customised ComponentsYes
Source DirectYes
Pure Modes3
Inputs/Outputs
Audio Inputs4
USB-A1 (rear)
Pre-OutSubwoofer
Power Amp Direct INNo
Number of terminals1 pair
Network
HEOS Multi-room and Streaming / Network Audio StreamingYes / Yes
Lossy FormatsMP3 / WMA / AAC
Lossless formatsFLAC HD 192/24 / WAV 192/24 / ALAC 192/24
DSD Audio Streamingup to DSD5.6
Internet radioTuneIn
Ethernet / Wi-FiYes / Yes (dual antenna / dual band)
BluetoothYes
Specifications
Power Output (8 / 4 Ohm RMS)60W / 80W
Frequency Response5Hz – 100kHz ±3 dB
Total Harmonic Distortion0.02%
Damping Factor100 and over
Others
FL Display3 line OLED
Variable Cross OverYes (40/60/80/100/120Hz)
Auto Power On / OffOptical In 1 / Optical In 2 / Coaxial In (Default: OFF)
Sleep / TimerYes
General
Available ColorsBlack
Power Consumption220W
Network Standby Consumption4.7W
Standby Consumption0.4W
Remote ControlYes
Maximum Dimensions (W x H x D)440 x 379 x 125mm (excluding antennas)
Weight10.8kg
