Recommended Amp Power:
Full Range: 100 – 200 W
Subwoofer: 300 W
Normal Impedance:
Full Range: 6 ohms
Subwoofer: 4 ohms
Minimum Impedance:
Full Range: 5.5 ohms
Subwoofer: 4 ohms
Sensitivity (dB @ 2.83 V 1m):
Full Range: 88 dB
Frequency Response (4π +/- 3 dB):
Full Range: 55 Hz – 20 kHz
Subwoofer: 28 Hz – 200 kHz
Tweeter Size:
Full Range: 2.5″ (63.5 mm)
Tweeter Type:
Full Range: UBD™ mid/high
Woofer Count:
Full Range: 2
Subwoofer: 3
Woofer Type:
Full Range: Coated Paper
Subwoofer: Coated Paper
Enclosure Size (H x W x D)
Full Range: 8 1/2 x 16 x 8 7/8″ (21.6 x 40.6 x 22.5 cm)
Subwoofer: 8 1/2 x 16 x 8 7/8″ (21.6 x 40.6 x 22.5 cm)
Product Weight:
Full-Range: 16.65 lbs. (7.55 kg)
Subwoofer: 16.15 lbs. (7.32 kg)
Shipping Weight:
Full-Range: 24 lbs. (10.8 kg)
Subwoofer: 23.5 lbs. (10.66 kg)
